Building a DNS Resolver from Scratch in Rust

A deep dive into implementing a DNS resolver using Rust, covering UDP sockets, DNS packet parsing, and recursive resolution.

Chaitanya

Source Code: https://github.com/cb7chaitanya/networking/tree/main/dns-resolver

DNS is often treated as background infrastructure, something that “just works.”

But behind every HTTP request, TLS handshake, and API call lies a distributed protocol that translates human-readable names into IP addresses.

This post walks through the implementation of a fully functional iterative DNS resolver written in Rust, including:

Manual DNS packet construction and parsing
Iterative resolution across root, TLD, and authoritative servers
Name compression decoding
EDNS0 support
Positive and negative caching
Failure handling (NXDOMAIN, SERVFAIL, timeouts)
Packet-level verification using Wireshark
Performance benchmarking (cold vs warm cache)
Concurrency scaling analysis

This is not a wrapper around libc.

It is a ground-up implementation of the DNS protocol.

Why Build a Resolver?

Most applications delegate DNS to recursive resolvers like Google Public DNS or Cloudflare.

Those systems perform:

Root lookup
TLD resolution
Authoritative resolution
Caching
Retry logic

In this project, the resolver performs iterative resolution itself.

That means:

Recursion Desired (RD) flag is disabled
The resolver follows referrals manually
Authority and Additional sections must be parsed correctly
Glue records must be extracted
Delegation must be handled explicitly

This makes the protocol transparent.

DNS Architecture Overview

DNS is a hierarchical distributed system:

Client
  ↓
Root Servers
  ↓
TLD Servers (.com, .org, etc.)
  ↓
Authoritative Name Serversplain text

The 13 logical root servers are coordinated by IANA under the oversight of ICANN.

A resolver must:

Query a root server
Receive a referral to a TLD server
Query the TLD server
Receive referral to authoritative server
Query authoritative server
Extract final answer

Each step requires correct parsing of the DNS message format.

DNS Message Format (Wire-Level Understanding)

A DNS message consists of:

Header (12 bytes)
Question section
Answer section
Authority section
Additional section

Header Structure

| Field          | Size    |
| -------------- | ------- |
| Transaction ID | 16 bits |
| Flags          | 16 bits |
| QDCOUNT        | 16 bits |
| ANCOUNT        | 16 bits |
| NSCOUNT        | 16 bits |
| ARCOUNT        | 16 bits |plain text

Important flags:

QR → Query/Response
RD → Recursion Desired
RA → Recursion Available
AA → Authoritative Answer
RCODE → Result Code

Because this resolver is iterative:

RD = 0plain text

Constructing DNS Queries

The resolver manually constructs:

DNS header
Question section
EDNS0 OPT record in the Additional section

EDNS0 extends UDP payload size beyond the traditional 512-byte limit.

Without EDNS0:

Large responses are truncated
TCP fallback is required

With EDNS0:

UDP payload up to 4096 bytes
Avoids unnecessary TCP fallback

Name Encoding and Compression

DNS encodes domain names as:

[length][label][length][label]...[0]plain text

Example:

07 example
03 com
00plain text

Responses frequently use compression pointers:

0xC0 0x0Cplain text

The first two bits 11 indicate a pointer
The remaining 14 bits represent the offset in the packet

Correct pointer decoding is critical to avoid:

Infinite loops
Incorrect label resolution
Offset corruption

This resolver handles nested pointers safely and enforces bounds to ensure correctness.

Iterative Resolution Logic

Resolution proceeds as follows:

Select a root server
Send an A record query
If Answer section present → return result
If referral → extract NS records from Authority section
Extract glue A records from Additional section
Select next nameserver
Repeat

Unlike recursive resolvers, this implementation must explicitly manage delegation.

That includes:

Parsing NS records
Handling glue
Rotating across multiple nameservers
Retrying when necessary

Packet-Level Verification (Wireshark Inspection)

To validate protocol correctness, DNS traffic was captured using Wireshark.

Root Query Packet

Key fields:

RD = 0
One question
One Additional record (OPT for EDNS0)
UDP port 53

This confirms:

Iterative resolution
EDNS0 support
Correct header construction

Root Referral Response

Typical response:

Answer RRs: 0
Authority RRs: multiple NS records for .com
Additional RRs: glue A records for TLD servers

The resolver correctly:

Parses NS records
Extracts glue IPs
Selects next hop

Authoritative Response

Final authoritative response includes:

AA flag set
Answer section populated
TTL value

The resolver extracts:

IP address
TTL
Expiration timestamp

Packet capture confirms wire-level compliance.

Annotated Real DNS Response

Example: A example.com

Header

QR = 1 (response)
RCODE = 0 (success)
ANCOUNT = 1

Compression Pointer

A pointer such as:

c0 0cplain text

Indicates reuse of the name starting at byte offset 12.

Answer Section

Type = A
Class = IN
TTL = 300
RDLENGTH = 4
RDATA = 93.184.216.34

This confirms:

Proper network-byte-order parsing
Compression decoding correctness
Accurate TTL extraction

Caching Design

The resolver implements:

Positive caching (A records)
Negative caching (NXDOMAIN)
TTL-based expiration

Data structure:

HashMap<Domain, CacheEntry>plain text

Each cache entry includes:

Result (IP or NXDOMAIN marker)
Expiration timestamp

Cache lookups avoid unnecessary network traversal and drastically reduce latency.

Failure Case Analysis

DNS failures are normal in distributed systems.

NXDOMAIN (RCODE = 3)

Indicates the domain does not exist.

Resolver behavior:

Stop resolution
Extract SOA record
Cache negative result
Respect negative TTL (RFC 2308)

This prevents repeated unnecessary queries.

SERVFAIL (RCODE = 2)

Indicates temporary failure.

Resolver behavior:

Attempt alternate nameservers
Retry with backoff
Avoid aggressive caching

Critical distinction:

NXDOMAIN → permanent
SERVFAIL → transient

Timeout Handling

If a UDP query receives no response:

Retry with exponential backoff
Rotate across available nameservers
Cap maximum retries

Prevents infinite resolution loops.

Performance Benchmarks

Test environment:

Local resolver
Residential broadband
100–10,000 parallel queries

Cold Cache Resolution

Includes:

Root query
TLD query
Authoritative query

Measured latency:

110–180 ms

Dominated by network RTT.

Warm Cache Resolution

All responses served locally.

Measured latency:

< 1 ms

Improvement:

~100x–150x faster

This illustrates why caching is fundamental to DNS scalability.

Concurrency Benchmarks

Concurrency implemented via:

Arc<RwLock<HashMap<...>>>plain text

Cold Cache (500 parallel queries)

Total time: ~350–600 ms
Avg latency: ~150 ms

Network-bound workload.

Warm Cache (5000 parallel queries)

Total time: ~15–25 ms
Avg latency: < 1 ms

Now limited by lock contention.

Throughput

Warm cache throughput:

~150k–250k queries/sec (local process)

Reveals:

DNS parsing is lightweight
Network traversal dominates latency
Lock design impacts scalability

Possible optimizations:

Sharded caches
Lock-free structures
Async runtime (Tokio)

What This Project Reveals

Implementing a DNS resolver from scratch demonstrates:

Backward-compatible protocol evolution (EDNS0 layered over RFC 1035)
Compression as a space optimization with parsing complexity
Delegation as a scalability mechanism
Caching as the primary performance amplifier
Failure handling as a first-class systems concern

DNS is not just name lookup.

It is:

A distributed system
A caching problem
A wire protocol exercise
A concurrency design challenge

Closing Thoughts

This resolver is not intended to replace production-grade systems such as BIND or Unbound.

It is designed to make the protocol transparent rather than abstract.

After implementing DNS manually:

Every curl request has visible mechanics
Every TLS handshake begins with a system you understand
Every latency spike has a traceable root

DNS stops being invisible infrastructure.

It becomes a system you can reason about byte by byte.
